Arena, GTX980, X4, resolutions, Windows monitor settings

[karamasov]

Hi, gang!
I have a problem - screen resolution and monitor sync with WIndows, Arena,
Spec:
Windows 8, Arena 5.1, 2x Nvidia GTX 980 and 2x Datapath X4 on DVI DL outputs.
Local monitor on HDMI from one of the 980s.

PC won¨t deliver more than 2560x1440 to the X4s.
X4s could of course receive 3840x2160 form the PC, but the PC doesn´t give that as an option.

Arena sees only weird outputs (3200x1800, 2400x1350...)

Additional problem: One of the beamers doesn´t accept 1080@60 (59.995), only 1080@30 (29.xx).

I´ve found this tool, but I´m not sure if that´s the solution:
http://www.monitortests.com/forum/Threa ... tility-CRU

Any ideas?

[elgarf]

Hi.

Can you attach screenshot of datapath configuration tool?

[Oaktown]

PC won¨t deliver more than 2560x1440 to the X4s.
X4s could of course receive 3840x2160 form the PC, but the PC doesn´t give that as an option.

It sounds like you may not have a good Dual-Link DVI cable and your signal flow is being throttled. Are you outputting DL-DVI directly from the DL-DVI output or using a DP to DL-DVI output? How long is your cable?

You will also find a Dual-Link Booster setting (1-7) in the Datapath UI that may help stabilize the signal.

Additional problem: One of the beamers doesn´t accept 1080@60 (59.995), only 1080@30 (29.xx).

You can change the output resolutions in the Datapath UI (either Datapath X4 or Wall Designer) for each of the 4 outputs so you can easily adjust that one output to 30 or 29.97 instead of 60 or 59.94,

[karamasov]

Thanks for the feedback guys.
Boosted the DVI in x4, good cables straight from Gfx DVI output, changes last projec to 29,97, reastrted two times, everything works OK.

Arena crashes, but thats anothjer thread *)

[Oaktown]

Glad to hear it's working now!

Make sure you save your settings in the X4.
